Film Impact Tester – HTZ 017 – Direct Manufacturer

GB 8809-88,ASTM D3420,NF T54-116
Technical specifications
Model | HTZ 017 |
Impact capacity | 1J, 2J, 3J, 5J (optional) |
Resolution | 0.001J |
Impact head size | Ф25.4mm, Ф19mm, Ф12.7mm (Customized available) |
Specimen holder size | Ф89mm, Ф60mm |
Specimen size | 100 mm x 100 mm, 100mm |
Gas resource pressure | 0.3MPa – 1.0MPa |
Gas resource interface | Ф6mm |
Instrument dimension | 492mm(L) × 383mm(B) × 752mm(H) |
Power supply | AC 220V 50Hz |
Net weight | 44kg |
Gross weight | 60kg |
Accessories: | |
mainframe, 1J pendulum, 2J capacity poise, 3J capacity poise, Ф25.4mm impact head, Ф19mm impact head, sample holder, micro-printer. | |
Optional parts: Professional software, non-standard impact head, O-rings. |
Feature
Film Impact Tester – HTZ 017 – Direct Manufacturer
- 1.TFT screen display results
- 2.Specimen pneumatic clamp
- 3.Pendulum pneumatic lock and release
- 4.Pendulum capacity easy to change
- 5.Statistic calculation: max, min, mean and standard deviation
- 6.Micro-printer prints mini-report
- 7.RS-232 standard communication port.
Standards
