EN71-1 8.17.1 Mouth-actuated Toy Durability Tester TW-229D

Mouth Actuated Toys Testing Equipment Durability Tester Touch Control Screen

ISO 8124-1 Mouth-actuated Toy Durability Tester

Mouth Actuated Toys Testing Equipment Durability Tester

Mouth-actuated Toy Durability Tester is suitable for the test of the safety of the Mouth-Actuated Toys, such as whistles with a ball, the sounders with a reed and other toys.

Standard :

EN71-1-2014+A1-2018 section 8.17.2;

ISO 8124-1 section 5.20

ASTM F963 section 8.13;

GB 6675.2 section 5.20

Testing of equipment

Load the mouth-actuated projectile toy with the intended projectile and apply a pressure of 13,8 kPa ± 5 % in the direction of the mouthpiece for 5 s.

Carry out the test 10 times in total.

Connect a piston pump capable of discharging and receiving more than 300 cm3 of air in less than 3 s to the mouthpiece of the toy. Arrange a relief valve so that the pump will not generate a positive or negative pressure of more than 13,8 kPa. Subject the toy to 10 alternating blowing and sucking cycles, each within 5 s and of at least (295 ± 10) cm3 of air including the volume which may be discharged through the relief valve. If the air outlet is accessible, ensure that the above is also applied to the outlet.

Determine whether any released component fits entirely in the small parts cylinder when tested according to 8.2 (small parts cylinder)

Technical specifications

1. Instruments to meet at least 295 cubic centimeters within + / -10 cubic centimeters of gas in 5s, and can be 10 times alternately blowing, suction.

2. apply a pressure of 13,8 kPa ± 5 % in the direction of the mouthpiece for 5 s.

3. Instrument install high precision pressure gauge (digital pressure gauge is optional if client need)

4.Supply gas-type fitting for different toys

5. Gas flow could be controlled by gas valve

6.Power: 220V/50Hz,4A.

7.Dimension (L*W*H):650*400*260mm

8.Weight: 20 kg
