IMADA Pointer Push Pull Tester FB-100LB
IMADA Pointer Push Pull Tester FB-100LB is a small and simple thrust and tensile force testing instrument. It is suitable for push and pull load test in electronic …
FB-100LB is a small and simple thrust and tensile force testing instrument. It is suitable for push and pull load test in electronic appliances, light industry and textile, hardware, lighter and ignition device, fire fighting equipment, manufacturing, fishing gear, power machinery, scientific research institutions and other industries.
It is a new generation of products that replace tubular push-pull force meters.
Technical Specifications
Model | FB-5 LB | FB-10 LB | FB-20 LB | FB-30 LB | FB-50 LB | FB-100 LB |
Capacity | 5 LB | 10 LB | 20 LB | 30 LB | 50 LB | 100 LB |
Minimum Read Value | 0.05 LB | 0.1 LB | 0.2 LB | 0.25 LB | 0.5 LB | 1 LB |
Accuracy | 士0.3%FS | |||||
Stroke | 10mm | |||||
Net Weight | 600g | |||||
Measuring Rod | M6 | |||||
Carry Temperature | -27°C~-+70C | |||||
Relative Humidity | 15%~-80%RH | |||||
Accessories | Pointer Push-Pull Force Gauge | 1 Pcs | ||||
Hard Plastic Packaging Case | 1 Box | |||||
Measuring probe | 5 Pcs | |||||
3 inch extension rod. | 1 Pcs | |||||
Features
1.Simple to operate, robust and virtually maintenance-free.
2.Ergonomic design, heavy duty metal case, no batteries required.
3.Can be used in hazardous environments.
4.Dial can be turned.
5.Real-time display and peak display modes.
6.All are genuine Japanese products.
Instructions
Please tightly hold gauge by hands or put it on appropriate stands to make a test.When testing,please adjust tested thing and gauge on the same straight line, if they are not.we will not get the correct tested value of load.
