IPX3 IPX4 Oscillating Tubes Rain Tester -Waterproof Tester WT 05

IPX3 IPX4 Oscillating Tubes Rain Test Chamber

IPX3 IPX4 Oscillating Tubes Rain Tester -Waterproof Tester

Simulate the damage of natural water (rain, seawater, river water, etc.) to products and materials, and waterproof testing of product casings.

Standard:

IEC60529:1989 +A1:1999 +A2：2013《Degrees of protection provided by enclosures(IP Code)》

GB/T4208-2017 Housing Protection Rating (IP Code) 14.2.3, 14.2.4

GB7000.1 Lamps Part I: General Requirements and Trials 9.2.4 , 9.2.5

Application

IPX3 IPX4 Oscillating Tubes Rain Tester -Waterproof Tester

For electrical products, outdoor lamps, electrical cabinets, electrical components, automobiles, motorcycles and their components and other products in simulated rainy climate conditions, the physical and other related properties of the product tested. After testing, the performance of the product is determined to meet the requirements, in order to facilitate product design, improvement, verification and factory inspection use.

Features

Suitable for product IPX3, IPX4 waterproof testing
The shell is made from domestic high-quality steel plate.
The chassis is equipped with a water storage tank, which automatically controls the water intake and prevents damage to the machine due to lack of water.
The use of high-quality servo motor, low noise, swing speed, angle more accurate..
Sample loading table using stepper motor, rotation speed and standard angle can be controlled bytouch screen.
Touch control function for IPX3 testing, IPX4 testing, customization:you can set the test time, rain angle, swing speed, turntable speed.
sample turntable: US304 stainless steel plate processing and manufacturing.
The power-off time of the sample power supply can be controlled by the program: power failure (0-999 min) – power on (0-999min) – power failure (0-999min), suitable for samples in the test need to power off.
The door has tempered glass windows and the box is equipped with LED lights for easy observation of internal testing.
The test chamber is equipped with a sample power outlet (standard AC220, 10A; can be customized on demand),then sample can be tested live.
