IPX8 Pressure Immersion Water Test Machine – Big Size WT 11

IPX8 Pressure Immersion Water Test Equipment

IPX8 Pressure Immersion Water Test Machine.Simulate the damage of natural water (rain, seawater, river water, etc.) to products and materials, and waterproof testing of product casings.

Standard:

IEC60529:1989 +A1:1999 +A2:2013
GB/T4208-2017 Housing Protection Rating (IP Code) 14.2.8
GB7000.1 Lamps Part I: General Requirements and Trials 9.2.9

Application

IPX8 Pressure Immersion Water Test Machine has been widely used in domestic commodity inspection bureau and the domestic and foreign products, quality authentication laboratory and the domestic and foreign well-known electronics manufacturers. Equipment performance had achieved the international advanced level, cost-effective.

Features

Suitable for product IPX7 + IPX8waterproof testing
The tank is made of 304 stainless steel, high-precision overall sub-arc welding forming, good pressure;
The immersion tank is made of SUS304 stainless steel
Special silicone seal ring, good elasticity, good durability.
Top tank cover on equipment – secured with 8 ring screws (send auxiliary-steel rod).
The equipment is equipped with a safety valve that automatically releases pressure after exceeding the rated pressure, preventing operator errors and hazards.
Electronic control components using imported brands (e.g. LS, Panasonic, Omron, etc.).
Using the imported Panasonic pressure sensor – automatic control tank test pressure, control accuracy: ± 002Mpa, sensor display accuracy: 0.001Mpa.
The equipment base is equipped with 4 casters for easy movement and fixation.
The outside of the tank is connected to a transparent tube, and the outer layer is fitted with a stainless steel ruler for a clear observation of the internal water level.
The inlet and drain valves are installed in the bottom position of the equipment.
Tank installation cylinder lifting device, smooth lifting, easy to work
