Transportation Vibration Tester TNJ-015-Supplier








Product Introduction
Transportation Vibration Tester-Transportation Vibration Test Machine-TNJ-015 is used for testing the vibration resistance of large furniture, home appliance,toys,electronices,gifts,packaging etc. Also can be used for simulating the transportation under vibration.
It is an indispensable test instrument for improving product quality. The simulated transport vibration table is mainly used to simulate the collision of goods and articles produced by the product in the car trunk when the vehicle encounters different road conditions such as bumps, uphills, downhills, corners, etc. Collision, extrusion of items and articles, etc., cause damage to the product, thereby further improving the quality of the article and the quality of the package. In order to obtain the basis for the assessment of the packaging of the articles and articles by obtaining the influence of the actual working conditions on the articles in the laboratory.
Technical specifications
Model | TNJ-015 |
Vibration Frequency | 100-300rpm |
Frequency Precision | 2rpm |
Allowed Max Load | 500 kg |
Vibration Speed | 100CPM-300 CPM |
Vibration Type | Rotary motion, Vertical vibration (Optional) |
Simulation Speed | 25km/h-40km/h |
The Worktable Size | 2000mm*10000mm (L*W) |
Barrier Height | 1000 mm |
Control Motor | AC frequency conversion motor |
The Power Supply Voltage | 380 v, 50 HZ,3 A |
The Machine Weight | About 350 kg |
The Whole Machine Size | 2100 mm * 1100 mm * 1450 mm (L*W*H) |
Features
1. Vibraiton frequency digital display, high precision.
2. Synchronous mute broadband transmission, very low noise.
3. Rail type fix clamp for test specimen, easy and safety.
4. Heavy steel channel base with damping rubber, easy installation, big load capacity, smooth operation.
5. Rotary vibration apply to EU and USA standards of transport.
6. Stainless steel working table.Adjustable speed electrical machine supply powerful motive power,strong loading ability.
Standards
GB/T4857.2
EN71, ANSI
UL,ISO2247
ASTM999
ISTA 1A
