IPX1 IPX2- Vertical Rain-Drip Shelf Tester -Waterproof Testing Equipment WT 03

WT 03 Vertical Rain Drip Tester Removable model 02

IPX1 IPX2- Vertical Rain-Drip Shelf Tester -Waterproof Testing Equipment is applied to test the water tightness of enclosures of automotive parts, outdoor lamps and electronics parts.

Standard:

IEC60529:1989 +A1:1999 +A2：2013《Degrees of protection provided by enclosures(IP Code)》

GB/T4208-2017 Housing Protection Rating (IP Code) 14.2.1, 14.2.2 and Figure 3

GB7000.1 Lamps Part I: General Requirements and Trials 9.2.3

Application

IPX1 IPX2- Vertical Rain-Drip Shelf Tester -Waterproof Testing Equipment

For electrical products, outdoor lamps, electrical cabinets, electrical components, automobiles, motorcycles and their components and other products in simulated rainy climate conditions, the physical and other related properties of the product tested. After testing, the performance of the product is determined to meet the requirements, in order to facilitate product design, improvement, verification and factory inspection use.

Features

Touch screen control, independently developed operating interface (based on customer requirements to install multiple languages), can directly choose waterproof level, the device will automatically in accordance with the standard terms of the waterproof rating conditions for testing;
Core control components use 7-inch touch screen + Panasonic PLC, and electrical components are made using imported brands such as LS .
Sample loading table using stepper motor, rotation speed and standard angle can be controlled by touch screen, IPX1 standard speed: 1r/min; IPX2 angle test can be completed automatically: 2.5min rain in 4 positions.
With air drying function, after the completion of the test, the water in the drip tank can be removed clean, to avoid long-term water fouling and block the pinhole.
The rainboard automatically rises and falls , it can automatically stops when the nozzle is located at the highest point of the tested object at 200mm.
Rainfall: with adjustment valve, can be adjusted manually.
The nozzle contact bit brass cone design makes it easy to change the needle without tools, and a stainless steel mesh shield is installed under the needle to prevent the test operator from being injured when the head touches the test needle.
Rain-drip plate: the use of vacuum design, the use of high rust-proof stainless steel material manufacturing.
Column structure, equipment running smoothly, the main frame can be packaged as a whole, convenient transportation, saving installation time.
sample turntable: US304 stainless steel plate processing and manufacturing.
The test chamber is equipped with a sample power outlet (standard AC220, 10A; can be customized on demand), then sample can be tested live.
The equipment base is equipped with 4 moving casters for easy movement and fixation
