IPX5 IPX6 Strong Jet Water Tester -Waterproof Test WT 06

IPX5 IPX6 Strong Jet Water Tester

Simulate the damage of natural water (rain, seawater, river water, etc.) to products and materials, and waterproof testing of product casings.

Standard:

IEC60529:1989 +A1:1999 +A2:2013
GB/T4208-2017 Housing Protection Rating (IP Code) 14.2.5, 14.2.6

GB7000.1 Lamps Part I: General Requirements and Trials 9.2.6, 9.2.7.

Application

IPX5 IPX6 Strong Jet Water Tester

The chambers built with the water tightness of sealed components such as head lamp, Power connector. Waterproof power connector in the test room can easily supply electricity to the specimens.

IPX5 and IPX6 functions on one test chamber,make testing convenient and cost-effective.

Features

Suitable for product IPX5, IPX6 waterproof testing
The shell is made from domestic high-quality steel plate.
The chassis is equipped with a water storage tank, which automatically controls the water intake and prevents damage to the machine due to lack of water.
The use of high-quality servo motor, low noise, swing speed, angle more accurate..
Sample loading table using stepper motor, rotation speed and standard angle can be controlled by touch screen.
The turntable electrical part is fully sealed, effectively preventing water inlet and leakage .
sample turntable: US304 stainless steel plate processing and manufacturing.
The power-off time of the sample power supply can be controlled by the program: power failure (0-999 min) – power on (0-999min) – power failure (0-999min), suitable for samples in the test need to power off.
Provides a special gun rack, so that testers do not need to hold a gun, easy to test.
